1. Use and scope of application
TD75 general belt conveyor features simple structure, large transport quantity, convenient operation and maintenance, low cost, versatile application and other advantages, and is widely applied to various fields including metallurgy, coal, transport, construction material, mine, harbor, etc. for transport of bulk materials and items packed in sets. The transmission distance and height of this product can be customized, and the maximum dip angle of transmission can reach 22°. The product is capable of long distance transport operation.
This conveyor is applicable to operation environment with temperature around -15℃~40℃. With corresponding protective measures applied, it can also operate under conditions with special requirements, such as explosion-proof, waterproof, corrosion/high temperature/cold resistant.
1.1 Technical features and structure diagram
Transport capacity of belt conveyor is below 2.5t/m3
Belt conveyor can be divided into the following categories according to belt width: 500, 650, 800, 1000, 1200, 1400
Belt conveyor can be divided into the following categories according to belt velocity: 0.8, 1.0, 1.25, 1.6, 2.0, 2.5, 3.15, 4.0
1. Head funnel 2.Head drum 3.Spring cleaner 4.Headstock 5.Carrying idler 6.Return idler 7.Landing leg 8.Middle frame 9.Tape carrier 10.Buffer idler 11.Nonload section cleaner 12. Material-guiding groove 13.Tailstock 14.Tail drum 15.Tension device
1.2 Main technical parameters
Type of carrying idler
Belt velocity
Belt width (mm)
500
650
800
1000
1200
1400
Conveyor Q (t/h)
Trough idler
Parallel idler
0.8
78
131
―
41
67
118
1.0
97
164
278
435
655
891
52
88
147
230
345
469
1.25
122
206
348
544
819
1115
66
110
184
288
432
588
1.6
156
264
445
696
1048
1427
84
142
236
368
553
753
2.0
191
323
546
853
1284
1748
103
174
289
451
677
922
2.5
232
391
661
1033
1556
2118
125
211
350
821
1117
3.15
824
1233
1858
2528
4.0
2202
2996
Notes: the transport capacity in the table is calculated when material volume-weight r=1.0t/m3, dip angle of conveyor = 0°~7°, and angle of move of material = 30°.
